Author: Lorenzo Fabbri

Rotvel Avio Stick

Technical datasheet

General description

The Rotvel Avio Stick is a color contrast penetrant for high temperature inspections with excellent resolution in detecting surface discontinuity indications. It generates an excellent red color contrast with good penetration characteristics. The penetrant is in the solid state; once in contact with the hot surface, it liquefies and penetrates into the possible discontinuities. For removal it is suggested to use a cloth soaked in Velemulsior H2O. Due to the remarkable penetrant fluidity, the formation of the indications is practically instantaneous after the application of the developer.

Packaging

Bags with 1 or more sticks

Part Number: 04099930

Features

  • Good penetration characteristics.

  • Intense and contrasting color.

  • Excellent discontinuities resolution.

Product Properties

Appearance

Opaque red solid

Method D
Sensitivity

Level 2

User Recommendations

NDT Method

High temperature dye liquid penetrat inspection


Usage temperature

From 50°C to 150°C

Recommended penetration time*

From 30 sec. to 3 min.

Developer

Rotrivel H2O Paste

Final cleaning

Velemulsior H2O

Shelf life

3 years at T between 5°C and 45°C, in a dry place safe from direct sunlight

Accessories EN ISO 3452

Stick holder

* For temperatures between 50°C and 80°C, the application time will be approximately 2-3 minutes. For temperatures between 80°C and 100°C, the application time will be approximately 1-2 minutes. For temperatures between 100°C and 150°C, the application time will be approximately 30 sec.-1 min.

Related products

Continue reading

CLT Group: our Partner for Telecommunications

CLT Group: our Partner for Telecommunications

 CLT Group has been providing for more than ten years now, the excellent service for CGM’s telephone and computer network. Thanks to their knowledge and professionalism, we can work with a convenient, fast and efficient system today.

Recently, Matteo Pettinari, our Technical Assistant Manager, was contacted by CLT Group for an interview, which formed the basis for the drafting of their new Case History article.

It was a pleasure for us to answer their questions and, by telling our experience and contribute in the creation of the newspaper article, which you can read at the below web site:

https://www.cltgroupsrl.it/cgm-cigiemme-spa/

Continue reading

Powder U 55+AC

Technical datasheet

General description

U 55+AC is a powder used for the preparation of a transparent water-based coupling gel, the viscosity of which can be adjusted according to the amount of water used. The gel obtained is suitable for the most common applications under normal conditions of use for both defect and thickness checks. It contains anti-corrosive so as not to affect the surfaces under examination. The product is non-toxic to skin, has no danger labelling and is not harmful to the environment.

Packaging

200 g envelope plastic bags

Part Number: 01049064

5 kg envelope plastic bags

Part Number: /

In Compliance with

  • ASME V Art.5 (T-533)

  • FAA AC 25-29 (glycerin free)

  • MIL-STD-271

  • PMUC (certificate of compliance upon request)

Features

  • Excellent solubility in water.

  • It allows to obtain: an excellent couplant, suitable for different types of surfaces, with excellent lubricating properties for ultrasonic transducers.

Product Properties

Appearance

White powder

Recommended dilution in potable water

33 g/l

User Recommendations

NDT Method

Ultrasonic testing

Usage temperature

From 5°C to 80°C

Shelf life

3 years at T between 5°C and 45°C, in a dry place safe from direct sunlight

Related products

Continue reading

Couplant U 53

Technical datasheet

General description

U 53 is a white water-based peeling gel. It is suitable for the most common applications under normal conditions of use for both defect and thickness checks. The presence of anti-corrosives prevents oxidation, so it is not essential to remove the gel after the check. The product is non-toxic to the skin, has no hazard labels and is not harmful to the environment. The characteristic of being peeling allows for faster removal of the residue.

Packaging

5 kg buckets

Part Number: 01049060

In Compliance with

  • ASME V Art.5 (T-533)

  • MIL-STD-271

  • PMUC (certificate of compliance upon request)

Features

  • Excellent coupling agent, suitable for different types of surfaces.

  • Excellent lubricant for ultrasonic transducers.

  • Excellent wettability of the surface under examination.

Product Properties

Appearance

White gel

Recommended dilution in potable water

0 to 1:1

User Recommendations

NDT Method

Ultrasonic testing

Usage temperature

From 5°C a 80°C

Shelf life

3 years at T between 5°C and 45°C, in a dry place safe from direct sunlight

Related products

Continue reading

Couplant U 51

Technical datasheet

General description

U 51 is a water-based white laminating gel. It is suitable for the most common applications under normal conditions of use for both defect and thickness checks. The presence of anti-corrosives prevents oxidation, so it is not essential to remove the gel after the check. The product is non-toxic to the skin, has no hazard labels and is not harmful to the environment.

Packaging

5 kg buckets

Part Number: 01049050

In Compliance with

  • ASME V Art.5 (T-533)

  • FAA AC 25-29 (glycerin free)

  • MIL-STD-271

  • PMUC (certificate of compliance upon request)

Features

  • Excellent coupling agent, suitable for different types of surfaces.

  • Excellent lubricant for ultrasonic transducers.

  • Excellent wettability of the surface under examination.

Product Properties

Appearance

White gel

Recommended dilution in potable water

0 to 1:1

User Recommendations

NDT Method

Ultrasonic testing

Usage temperature

From 5°C to 80°C

Shelf life

3 years at T between 5°C and 45°C, in a dry place safe from direct sunlight

Related products

Continue reading

Couplant U 49

Technical datasheet

General description

U 49 is a water-based transparent peeling gel. It is suitable for the most common applications under normal conditions of use for both defect and thickness checks. The presence of anti-corrosives prevents oxidation, so it is not essential to remove the gel after the check. The product is non-toxic to the skin, has no hazard labels and is not harmful to the environment. The characteristic of being peeling allows for faster removal of the residue.

Packaging

5 kg buckets

Part Number: 01049040

In Compliance with

  • ASME V Art.5 (T-533)

  • MIL-STD-271

  • PMUC (certificate of compliance upon request)

Features

  • Excellent coupling agent, suitable for different types of surfaces.

  • Excellent lubricant for ultrasonic transducers.

  • Excellent wettability of the surface under examination.

Product Properties

Appearance

Transparent gel

Recommended dilution in potable water

0 to 1:1

User Recommendations

NDT Method

Ultrasonic testing

Usage temperature

From 5°C to 80°C

Shelf life

3 years at T between 5°C and 45°C, in a dry place safe from direct sunlight

Related products

Continue reading

Couplant U 47

Technical datasheet

General description

U 47 is a water-based transparent laminating gel. It is suitable for the most common applications under normal conditions of use for both defect and thickness checks. The presence of anti-corrosives prevents oxidation, so it is not essential to remove the gel after the check. The product is non-toxic to the skin, has no hazard labels and is not harmful to the environment.

Packaging

5 kg buckets

Part Number: 01049030

In Compliance with

  • ASME V Art.5 (T-533)

  • FAA AC 25-29 (glycerin free)

  • MIL-STD-271

  • PMUC (certificate of compliance upon request)

Features

  • Excellent coupling agent, suitable for different types of surfaces.

  • Excellent lubricant for ultrasonic transducers.

  • Excellent wettability of the surface under examination.

Product Properties

Appearance

Transparent gel

Recommended dilution in potable water

0 to 1:1

User Recommendations

NDT Method

Ultrasonic testing

Usage temperature

From 5°C to 80°C

Shelf life

3 years at T between 5°C and 45°C, in a dry place safe from direct sunlight

Related products

Continue reading

Green Gel U 45

Technical datasheet

General description

Green Gel U 45 is a water-based thixotropic green coupling gel that can be used in the temperature range -20°C / 120°C. It is composed by anti-corrosive so as not to affect the surfaces being tested. Suitable for use on various types of surfaces, smooth or uneven, it is also recommended for non-optimal situations, such as vertical and underhead inspections. Moreover, as it fluoresces under UV light, it is easy to detect and remove. The product is non-toxic to the skin, has no hazard labelling and is not harmful to the environment.

Packaging

5 kg buckets

Part Number: 01049015

1 kg jar

Part Number: 01049015

In Compliance with

  • ASME V Art.5 (T-533)

  • FAA AC 25-29 (glycerin free)

  • MIL-STD-271

  • PMUC (certificate of compliance upon request)

Features

  • Excellent coupling agent, suitable for different types of surfaces, smooth or irregular, and also recommended for non-optimal situations, such as overhead checks.

  • Fluorescent under UV light for an easy detection and removal.

  • Dry very slowly.

Product Properties

Appearance

Transparent green gel

Recommended dilution in potable water

0 to 1:1

User Recommendations

NDT Method

Ultrasonic testing

Usage temperature

From Da -20°C to 120°C

Shelf life

3 years at T between 5°C and 45°C, in a dry place safe from direct sunlight

Related products

Continue reading
